Developer environments – new capabilities to create for users

Developer environments are awesome. There – I’ve said it for the record. Formerly known as the ‘Community Plan’, developer environments are there for users to be able to play with things, get up to speed, test out new functionality, etc. They’re free to use – even with premium capabilities & connectors, users do not need premium licensing in place (caveat – if it’s enabled as a Managed Environment, it will require premium licensing).

Originally, users were only able to create a single developer environment. However, earlier on this year Microsoft lifted this restriction – users are now able to create up to THREE developer environments for their own usage (which makes it even easier now for users to get used to ALM capabilities, and try it out for themselves).

Now, the ability for users to create developer environments is controlled at the tenant level, and it’s either On or Off. It requires a global tenant admin to modify this setting, but it’s not possible to say ‘User Group A will not be able to create developer environments for themselves, but User Group B will be able to’.

Organisations have differing viewpoints on whether they should allow their users the ability to create developer environments or not. I know this well, as usually I’m part of conversations with them when they’re debating this.

One of the main challenges that comes when organisations don’t allow users to create their own developer environments has been that historically, it’s not been possible for someone else to create the environment on their behalf. If we think of ‘traditional IT’, if we’re not able to do something due to locked down permissions, we can usually ask ‘IT’ to do it for us, and grant us access. This has not been the case with developer environments though – well, not until recently.

Something that I do from time to time is chat with the Microsoft Product Engineering groups, to provide feedback to (try to!) help iterate products forward and better. One of the conversations I had in the summer was with the team responsible for developer environments. I was able to share experiences & conversations that I had been having with large scale enterprise organisations, and (very politely!) asked if they could look to open up the ability to do something around this.

Around a month ago or so, the first iteration of this dropped – in the Power Platform Admin Centre interface, it was now possible to specify the user for whom an environment was to be created!

This was an amazing start to things, and definitely would start unblocking Power Platform IT teams to enable their users, in circumstances where their organisations had decided to turn off the ability for users to create their own developer environments.

However, this still required the need to do it manually. Unless looking into an RPA process (which, let’s face it, would be clunky & undesirable), it meant that someone with appropriate privileges would need to go & actually create the environment, and associate it to the user.

However, this has now taken another MASSIVE step forward – I’m delighted to announce that this capability has been implemented in the Power Platform CLI, and is live RIGHT NOW (you’ll need to upgrade to the latest version – it’s present in 1.28.3 onwards).

So, with this in place, it’s now possible to use PowerShell commands to be able to create developer environments on behalf of users, and assign it to them. Organisations usually already have PowerShell scripts to handle new joiners, and will therefore be able to integrate this capability into these, to automatically set up developer environments for users. Alternatively, existing users could look to raise internal requests, and have them automated through the use of PowerShell (along with appropriate approval processes, of course!).

So this is really nice to see. However, I think it can still go one step further (at least!), and am trying to use my connection network to raise with the right people.

See, we have the Power Platform for Admins connector within Power Platform already. One of the functions available in this is to be able to create Power Platform environments:

However, if we look at the action (& the advanced settings within this action), there’s no ability to set this:

Interestingly enough, the API version listed by default is actually several years old. By doing some digging around, I can see that there are multiple later API versions, so I’m not sure why it’s using an older one by default:

What would be really amazing is to have these capabilities surfaced directly within Power Platform, using this connector. Then we could look to have everything handled directly within Power Platform. Given that the CoE toolkit already includes an Environment Request feature, I would see this as building on top & enabling it even further. Obviously organisations wouldn’t need the CoE toolkit itself, as they could look to build out something custom to handle this.

What are your thoughts on this – how do you see these features enabling your organisation? If your organisation HAS locked down the ability for users to provision developer environments, are you able to share some insights as to why? I’d love to hear more – drop a comment below!¬

New Power Platform Security Role Editor

We’ve all been there. Security role wise, that is. It’s the point in any project where we start looking at configuring user security. To do this, we’ve used the Security Role section in the Settings area (once it’s actually loaded, of course):

Ah, the joys of this – dating back to CRM 3.0 (to my recollection – though it possibly might be 4.0). All of these lovely little circles, which fill up more & more as we click on them, whilst trying to work out what each one actually does:

And that’s not to mention the ‘Missing Entities’ tab (did anyone ever figure out what this was supposed to be used for), or the ‘Custom Entities’ tab which seemed like a catch all place. Plus the fact that non-table permissions (eg Export to Excel) were placed on random tabs that meant we needed to hunt through each tab to find the appropriate item.

Now many of us spend hours in here (then further hours once we started troubleshooting user issues that were down to security role misconfiguration). The absolutely ‘JOYS‘ of the header title row not being scrollable (though it was possible to hover over each permission, and it would tell you what it was). The power of clicking on the line item, and seeing ALL of the little circles fill up – if you haven’t ever done it, you’ll not have experienced the bliss that this could bring!

But all things come to an end(or as the Wheel of Time series says:’ The Wheel of Time turns, and Ages come and pass, leaving memories that become legend‘), and now we have a NEW security role experience.

First of all, the UI has changed. It’s cleaner, responsive, gives more information to users upfront….and the heading SCROLL!!!

We’re able to show just the tables that have permissions assigned to them (rather than wading through dozens or hundreds of entries that have no relevance), or show everything:

Oh, and those random non-table privileges that we had to try to find beforehand – these are now grouped very nicely. This is SO much easier to manage!

We can also take permissions that have been set on a specific table, and then copy them to another table (it promps us to select – and we can select MULTIPLE tables to copy to!):

But best of all is the way that we can now set permissions for items. There are several different ways of doing this.

Firstly, Microsoft has now provided us with the ability to select standard pre-defined options. Using these will set permissions across all categories for the item appropriately:

This is really neat, and is likely to save quite a bit of time overall. However if we’re needing to tweak security permissions to custom settings, we can do this as well. Instead of clicking on circles, we now have lovely dropdowns to use:

In short, I’m absolutely loving this. The interface is quick to load, intuitive, and works well without fuss.

Given how much time I’ve spent over the years in wrestling with security roles, I think this is going to be a definite timesaver for so many people (though we’ll still need to troubleshoot interesting error messages at times that testing will throw up, and work out how/what we’re needing to tweak for security access to work).

There are still some tweaks that I think Microsoft could make to get this experience even better. My top three suggestions would include:

  • The ability to select multiple lines, and then set a permission across all of them (sort of like bulk editing)
  • Being able to have this area solution aware. When we have various different projects going on, it would be great to have the ability to filter the permissions grid by a solution. This would be a timesaver, rather than having to wade through items that aren’t relevant
  • Export to Excel. Having a report generated to save digitally or print off is amazing for documentation purposes. There are 3rd party tools (thank you XrmToolBox!), but it would be great to be built into here

Overall, I’m really quite happy and impressed with it (it’s definitely taken enough time for Microsoft to pay attention to this, and get it out), and hope that it’ll continue to improve!

What have your bugbears with the legacy security editor been over the years, and how are you liking the new experience? Drop a comment below – I’d love to hear!

The story of MFA & the Centre of Excellence

I’ve been rolling out the Microsoft Centre of Excellence solution for several years now at customers. It’s a great place to start getting a handle on what exactly is going on within a Power Platform tenant, though there’s obviously so much more that takes place within a Centre of Excellence team.

The solution gathers telemetry around environments, Power Apps, Power Automates etc through the usage of the Power Automate Admin connectors for Power Platform (see Power Platform for Admins – Connectors | Microsoft Learn for further information on these).

Now obviously we need a user account to run these, and this usually has been through the use of a ‘pseudo service account’, as using a service principal has been tricky, to say the least. So we would get customers to set up an appropriate account with licensing & permissions in place, and use this to own & run the Power Automate flows that bring in the information to the CoE solution.

It is important to note that usage of these connectors do require a pretty high level of permissions – in fact, we usually suggest applying the Power Platform Admin security role (within the Microsoft 365 Admin Centre) to the user account. All good so far.

The tricky part has, to date, been around security. Organisations usually require (for good reasons) multi-factor authentication to be in place (aka MFA). Now this is fine for users logging in & accessing systems. However, it proves to be somewhat tricker for automations.

See, when a user logs in & authenticates through MFA, a token is stored to allow them to access systems. Automations can also use this. However the token will expire at some point (based on how each organisations has implemented MFA access/controls). When the token expires, the automations will stop running, and fail silently. There’s no prompt that the token has expired, and the only way of knowing is to take a look at the Power Automate flow history. This can be interesting though, as signing in (with the pseudo service account) will prompt for MFA authentication, and then everything will start running again!

So this has usually resulted in conversations with the client to politely point out that implementing MFA on the service account will mean that, at some point, the Power Automate flows are going to start failing. Discussions with security teams take place, mitigation using tools such as Azure Sentinel are implemented, and things move ahead (cautiously). It’s been, to date, the most annoying pain for the technical implementation (that I can think of at least, in my experience).

Now you’d think that a change in this would be shouted from the rooftops, people talking about it, social media blowing up, etc. Well, I was starting an implementation recently for a customer, and was talking to them around this, as I’d usually do. Imagine my surprise when Todd, one of the Microsoft technical people attached to the client, asked why we weren’t recommending MFA.

Taking a look at the online documentation, I noticed that something had slipped in. Finally there was the ability to use MFA!

Trawling back through the GitHub history (after all, I wanted to find out EXACTLY when this had slipped in), I discovered that it was a few months old. I was still very surprised that there hadn’t been more publicity around this (though definately a good incentive to write about it, and a great blog post to start off 2023 with!).

So moving forward, we’re now able to use MFA for the CoE user account. This is definately going to put a lot of mind at rest (especially those who are in security and/or governance). The specifics around the MFA implementation can be found at Conditional access and multi-factor authentication in Flow – Power Automate | Microsoft Learn – but it’s important to note that specific MFA policies will need to be set up & implemented for this account.

So, now the job will be to retro-fit this to all organisations that already have the CoE toolkit in place. Thankfully this shouldn’t be too difficult to do, and will most definitely enhance the security controls around it!

Have you implemented any mitigation in the past to handle non-MFA? I’m curious if you have – please drop a comment below!

New Platform DLP Capabilities

DLP (or Data Loss Prevention) is a very important capability in the Power Platform. With being able to bring together multiple data sources, both within the Microsoft technology stack as well as from other providers gives users amazing capabilities.

However with such great capabilities comes great responsibility. Of course, we trust users to be able to make proper judgements as to how different data sources can be used together. But certain industries require proper auditing around this, and so being able to specify DLP policies are extremely important to any governance team.

Being able to set how data connectors can be used together (or, in the reverse, not used together) across both Power Apps as well as Power Automate flows is imperative in any modern organisation.

To date, Power Platform DLP capabilities have existed that allow us to be able to categorise connectors (whether Microsoft provided or custom) into three categories. These categories specify how the connectors are able to function – they’re able to work with other connections that are in the same category group, but cannot work with connectors that are in a different category group.

So for example, it’s been possible to allow a user to create a Power App or a Power Automate flow that interacts with data from Dataverse, but cannot interact with Twitter (in the same app or flow).

With this approach, it’s possible to create multiple DLP policies, and ‘layer’ them as needed (much like baking a 7 layer cake!) to give the functionality required per environment (or also at the tenant level).

Now this has been great, but what has been missing has been the ability to be more granular in the approach to this. What about if we need to read data from Twitter, but just push data out to Twitter?

Well, Microsoft has now iterated on the DLP functionality available! It’s important to note that this is per connector, and will depend on the capabilities of the connector. What we’re now able to do is to control the specific actions that are contained within a connector, and either allow or not allow them to be able to be utilised.

Let’s take the Twitter connector as an example:

We’re able to see all of the actions that the connector is capable of (the scroll bar on the side is a nice touch for connectors that have too many actions to fit on a single screen!). We’re then able to toggle each one to either allow or disallow it.

What’s also really nice are the options for new connector capabilities.

This follows in the footsteps of handling connectors overall – we’re able to specify which grouping they should come under (ie Business, Non-Business, or Blocked). As new connectors are released by Microsoft, we don’t need to worry that users will automatically get access to them.

So too with new actions being released for existing connectors (that we’ve already classified). We’re able to set whether we want them to be automatically allow, or automatically blocked. This means that we don’t need to be worried that suddenly a new connector action will be available for users to use, that they perhaps should not be using.

From my perspective, I think that any organisation that’s blocking one or more action capabilities for a connector will want this to be blocked by default, just to ensure that everything remains secure until they confirm whether the action should be allowed or not.

So I’m really pleased about this. The question did cross my mind as to whether it would be nice to be able to specify this on a per environment basis when creating a tenant-level policy, but I guess that this would be handled by creating multiple policies. The only issue I could see around this would be the number of policies that could need to be handled, and ensuring that they’re named properly!

Have you ever wanted these capabilities? How have you managed until now, and how do you think you’ll roll this out going forward? Drop a comment below – I’d love to hear!

Security Roles & Assigning Records

Let’s face it, and call a spade a spade (or a shovel, depending on where in the world you happen to be). Security roles are very important within Dataverse, to control what users can (& can’t!) do within the system. Setting them up can be quite time-consuming, and troubleshooting them can sometimes be a bit of a nightmare.

Obviously we need to ensure that users can carry out the actions that they’re supposed to do, and stop them doing any actions that they’re not supposed to do. This, believe it or not, is generally common sense (which can be lacking at times, I’ll admit).

Depending on the size of the organisation, and of course the project, the number of security roles can range from a few, to a LOT!

Testing out security can take quite a bit of time, to ensure that testing covers all necessary functionality. It’s a very granular approach, and can often feel like opening a door, to then find another closed door behind the first one. Error messages appear, a resolution is implemented, then another appears, etc…

Most of us aren’t new to this, and understand that it’s vitally important to work through these. We’ve seen lots of different errors over our lifetime of projects, and can usually identify (quickly) what’s going on, and what we need to resolve.

Last week, however, I had something new occur, that I’ve never seen before. I therefore thought it might be good to talk about it, so that if it happens to others, they’ll know how to handle it!

The scenario is as follows:

  • The client is using Leads to capture initial information (we’re not using Opportunities, but that’s a whole other story)
  • Different teams of users have varying access requirements to the Leads table. Some need to be able to view, some need to be able to create/edit, and others aren’t allowed to view it at all
  • The lead process is driven by both region (where the lead is located), as well as products (which products the lead is interested in)

Now, initially we had some issues with different teams not having the right level of access, but we managed to handle those. Typically we’d see an error message along the following lines:

We’d then use this to narrow down the necessary permissions, adjust the security role, re-test, and continue (sometimes onto the next error message, but hey, that’s par for the course!).

However, just as we thought we had figured out all of the security roles, we had a small sub-set of users report an error that I had NEVER seen before.

The scenario was as follows:

  • The users were able to access Lead records. All good there.
  • The users were able to edit Lead records. All good there.
  • The users were trying to assign records (ie change the record owner) to another user. This generally worked, but when trying to assign the record to certain users, they got the following error:

Now this was a strange error. After all, the users were able to open/edit the lead record, and on checking the permissions in the security role, everything seemed to be set up alright.

The next step was to go look at the error log. In general, error logs can be a massive help (well, most of the time), assuming that the person looking at it can interpret what it means. The error log gave us the following:

As an aside, the most amusing thing about this particular error log, in my opinion, was that the HelpLink URL provided actually didn’t work! Ah well…

So on taking a look, we see that the user is missing the Read privilege (on what we’re assuming is the Lead table). This didn’t make sense – we then went back to DOUBLE-check, and indeed the user who was trying to carry out the action had read privileges on the table. It also didn’t make sense, as the user was able to open the lead record itself (disclaimer – I’ve not yet tried doing a security role where the user has create/write access to a table, but no read access..I’m wondering what would happen in such a scenario)

Then we had a lightbulb moment.

photo of bulb artwork

In truth, we should have probably figured this out before, which I’ll freely admit. See, if we take a look at the original error that the user was getting, they were getting this when trying to assign the record to another user. We had also seen that the error was only happening when the record was being assigned to certain users (ie it wasn’t happening for all users). And finally, after all, the error message title itself says ‘Assignee does not hold the required read permissions’.

So what was the issue? Well, it was actually quite simple (in hindsight!). The error was occurring when the record was being attempted to be assigned to a user that did not have any permissions to the Lead table!

What was the resolution? Well, to simply grant (read) access to the Lead table, and ensure that all necessary users had this granted to them! Thankfully a quick resolution (once we had worked out what was going on), and users were able to continue testing out the rest of the system.

Has something like this ever happened to you? Drop a comment below – I’d love to hear the details!

Troubleshooting the ‘Follow’ functionality

On a recent client project, we’ve come up against an interesting situation. Some of the users have the ‘Follow’ functionality available to them, but others don’t seem to have it. This, of course, is quite confusing, so I thought it would be good to write about it, for others who may come up against this.

But first, let’s take a step back. After all, before this had happened I had never heard of the ‘follow’ functionality within the system, and I’m quite sure that many others haven’t either! So what exactly is this all about?

What is ‘Follow’?

We’ve all been there – we have some customers who are ‘priority customers’, and we want to know/see everything that’s happening around them. Obviously we can go into their specific record/s, and see what’s going on. For example, seeing new cases added for these customers, other activities, etc. But what if we don’t want to have to manually open the records each time, or set up specific views in the system for them?

Well, this is where the Follow functionality comes in. It’s possible to track activities (in ‘real-time’) for records that a user follows. Microsoft has given us the ability to set this (or unset this) on a per record basis, so that users can set their own preferences within the system. When a user follows a specific record, the details for that record then show up in the users activity feed. This can then be used further, such as displaying it within a dashboard, for example.

Follow functionality through views
Follow functionality on a specific record

It’s also possible to automatically follow records based on specific criteria.

How to set up Follow functionality

In order for records to be able to have the follow functionality available to them, they need to have the Activity Feed enabled for the specific table. The default system tables such as Accounts, Contacts & Leads already have this enabled, so these records are able to be followed without any additional configuration around them.

To enable other tables (such as custom tables that you may have created) to be able to have the records within them followed, we need to carry out the following steps:

  1. Go to the Advanced Settings menu, and open Activity Feeds Configuration

2. Find the table that we’re wanting to configure this for (if it’s not showing up, click the ‘Refresh’ button on the menu)

Here we can see that the Channel table isn’t enabled at this point

3. Click the ‘Activate’ button on the menu bar

4. Confirm the pop up screen

And voila – you’re done! Users will now be able to go into the table/s, and follow (or unfollow) records there

Troubleshooting

So we now understand what the follow functionality is, and how to enable it. But what happens when users can’t actually see it within the system, to be able to use it?

Well, there are several different things that we can do to look to solve the issue:

  • Have activity feeds been configured for the table? If they’ve not been configured, then they’ll need to have this set up (this is why I’ve put the steps above as to how to do this!)
  • Are security roles set up correctly?

The second one is what turns out to have been the issue for this project. It’s been quite confusing, as originally mentioned, that certain users did see the follow functionality, but others users didn’t see it.

The first place to check is the ‘follow’ privileges on each security role:

As you can see above, we had given organisation-level access on the security role (& actually across all security roles), though the users were still having issues. So the next step is to check a different security privilege within the security role. This is the ‘Post Configuration’ setting, which is found under the Custom Entities section (why it’s under Custom, I have NO idea):

Without this enabled, users with the security role will NOT be able to see/use the follow functionality within the system!

Hopefully this should then sort out all issues, and users will be able to use the functionality as required.

Have you ever had issues with this feature? Have you found a different solution to fix it? Drop a comment below – I’d love to hear!

Record security with Power Automate

Today’s post is around record security, and how Power Automate can really be quite useful with this!

Let’s take a quick recap of how security works (which is applicable to both Dynamics 365, as well as Power Platform apps). We have the following:

  • Security roles, which are set up with specific privileges (Create/Read/Update/Delete etc) across each entity table, as well as for other system permissions
  • Users, who can have one (or more) security roles applied to them (security roles being additive in nature)
  • Teams, who can have one (or more) security roles applied to them. Users are added into the team, and inherit all permissions that the team has (much easier than applying multiple roles on a ‘per user’ basis)

That’s great for general security setup, but it does take a system admin to get it handled. Alternatively, of course, it’s possible to use AAD Security Groups which are connected to security teams within Power Platform, and users added to them will inherit the necessary permissions.

But what if we want to allow users who aren’t system administrators to allow other users access to the records? Well, it’s also possible to share a specific record with another user – doing this allows the second user to see/access the record, even if they usually wouldn’t be able to do so. This is really great, but does require a manual approach (in that each record would need to be opened, shared with the other user/s, and then closed).

I’ve been working on a project recently where we have the need to share/un-share a larger number of records, but with a different user for each record. We’ve been looking into different ways of doing this, and obviously Power Automate came into mind! We didn’t want to use code for this, for a variety of reasons.

Security and Compliance in PowerApps and Flow - Michał Guzowski Consulting

The scenario we had in mind was to have a lookup to the User record, and with populating this with a user, it would then share the record with them. This would be great, as we could bulk-update records as needed (even from an integration perspective), and hopefully all would work well.

So with that, I started to investigate what options could be available. Unfortunately, there didn’t seem to be any out of the box connectors/actions that could be used for this, which was quite disheartening.

My next move was to look at the user forums, & see if anyone had done anything similar. I was absolutely excited to come across a series of responses from Chad Althaus around this exact subject! It turns out that there’s something called ‘Unbound Actions’, which is perfect for the scenario that we’re trying to achieve.

There are two types of actions available within Power Automate:

  • Bound actions. This are actions that target a single entity table or a set of records for a single entity table
  • Unbound actions. These aren’t bound to an entity type and are called as static operations. They can be used in different ways

There are quite a lot of unbound actions available to use:

The one I’m interested in for this scenario is the GrantAccess action. More information around this can be found at https://docs.microsoft.com/en-us/dynamics365/customer-engagement/web-api/grantaccess?view=dynamics-ce-odata-9

It does require some JSON input, but when formatted correctly, it shows along the following lines:

The different parts of this works as follows:

  • Target is the actual record we’re wanting to apply the action to
  • SystemUserID is the actual system user, and we also need to specify the odatatype
  • AccessMask is what we’re wanting to do when sharing the record (as there are different options available for sharing, ie ReadOnly, Edit, ShareOnwards, etc)

Using this, we’ve therefore built out the following scenario:

  1. Field added to the record, looking up to Users
  2. Relevant users who are able to access the record can set this lookup field to be a specific user record (who doesn’t have access to this record)
  3. Power Automate flow fires on the update of the record when it’s saved (filtering on just this attribute), sharing the record with the selected user
  4. The user then gets an email to notify them that the record has been shared with them, with a URL link to it (it’s somewhat annoying that there’s no inbuild system notification when a record has been shared with you, but I guess that’s something we’re having to live with!)
  5. They can then go in & access the record as they need to

We’ve also given some thought to general record security, and have additionally implemented the following as well:

  1. If the user lookup value is changed, we obviously share the record with the new user that’s been saved to it
  2. Using a different Unbound Action (RevokeAccess), we remove the sharing of the record with the previous user (we have another field that’s being updated with the value of it, which we’re using to pass the action in, as otherwise we don’t actually know who the previous user was!)

All in all, we’re quite happy that we’ve managed to come up with this solution, which is working splendidly for us. Also, major thanks to Chad for his assistance in getting the syntax correct!

Have you ever needed to do something like this? Did you manage to implement it in some way? Drop a comment below – I’d love to hear how your experience was!

Data Export Service Connection Issues

This is a slightly different post from the usually stuff that I talk about. It’s much more ‘techy/developer’ focused, but I thought it would be quite useful still for people to keep in mind.

The background to this comes from a project that I’ve been working on with some colleagues. Part of the project involves setting up an Azure SQL database, and replicating CDS data to it. Why, I hear you ask? Well, there are some downstream systems that may be heavy users of the data, and as we well know, CDS isn’t specifically build to handle a large number of queries against it. In fact, if you start hammering the CDS layer, Microsoft is likely to reach out to ask what exactly you’re trying to do!

Therefore (as most people would do), we’re putting in database layer/s within Azure to handle the volume of data requests that we’re expecting to occur.

Azure SQL Database | Microsoft Azure

So with setting up things like databases, we need to create the name for them, along with access credentials. All regular ‘run of the mill’ stuff – no surprises there. In order for adequate security, we usually use one of a handful of password generators that we keep to hand. These have many advantages to them, such as ensuring that it’s not something we (as humans) are dreaming up, that might be easier to be guessed at. I’ve used password generators over the years for many different professional & personal projects, and they really are quite good overall.

Sordum Random Password Generator Creates Random Passwords with Ease - MajorGeeks
Example of a password generation tool

Once we had the credentials & everything set up, we then logged in (using SQL Server Management Studio), and all was good. Everything that we needed was in place, and it was looking superb (from the front end, at least).

OK – on to getting the data actually loaded in. To do this, we’re using the Data Export Service (see https://docs.microsoft.com/en-us/power-platform/admin/replicate-data-microsoft-azure-sql-database for further information around this). The reason for using this is that the Data Export Service intelligently synchronises the entire database initially, and thereafter synchronises on a continuous basis as changes occur (delta changes) in the system. This is really good, and means we don’t need to build anything custom to handle it. Wonderful!

Setting up the Data Export Service takes a little bit of time. I’m not going to go into the details of how to set it up – instead there’s a wonderful walkthrough by the AMAZING Scott Durow at http://develop1.net/public/post/2016/12/09/Dynamic365-Data-Export-Service. Go take a look at it if you’re needing to find out how to do it.

So we were going through the process. Part of this is needing to copy the Azure connection string into into a script that you run. When you do this, you need to re-insert the password (as Azure doesn’t include it in the string). For our purposes (as we had generated this), we copied/pasted the password, and ran things.

However all we were getting was a red star, and the error message ‘Unable to validate profile’.

As you’d expect, this was HIGHLY frustrating. We started to dig down to see what actual error log/s were available (with hopefully more information on them), but didn’t make much progress there. We logged in through the front end again – yes, no problems there, all was working fine. Back to the Export Service & scripts, but again the error. As you can imagine, we weren’t very positive about this, and were really trying to find out what could possibly be causing this. Was it a system error? Was there something that we had forgotten to do, somewhere, during the initial setup process?

It’s at these sorts of times that self-doubt can start to creep in. Did we miss something small & minor, but that was actually really important? We went over the deployment steps again & again. Each time, we couldn’t find anything that we had missed out. It was getting absolutely exasperating!

Finally, after much trial & error, we narrowed the issue down to one source. It’s something we hadn’t really expected, but had indeed caused all of this to happen!

What happened was that the password that we had auto-generated had a semi-colon (‘;’) in it. In & of itself, that’s not an issue (usually). As we had seen, we were able to log into SSMS (the ‘front-end’) successfully, with no issues at all.

However when put into code, Azure treats the semi-colon as a special character (a command separator). It was therefore not recognising the entire password, which was causing the entire thing to fail! To resolve this was simple – we regenerated the password to ensure that it didn’t include a semi-colon character within it!

Now, this is indeed something that’s quite simple, and should be at the core of programming knowledge. Most password generators will have an option to avoid this happening, but not all password generators have this. Unfortunately we had fallen subject to this, but thankfully all was resolved in the end.

The setup then carried on successfully, and we were able (after all of the effort above) to achieve what we had set out to do initially.

Have you ever had a similar issue? Either with passwords, or where something worked through a front-end system, but not in code? Drop a comment below – I’d love to hear!

Marketing & an unusual error

I’ll be the first to admit that I have limited experience of Dynamics 365 for Marketing. In fact, I think that it would be stretching the description to say that I have even ‘limited experience’! I’ve seen it one or twice, and have attended a few presentations on it, but apart from that, nada.

I do remember what it used to be like in its previous incarnation, but even then I didn’t really touch it. Customer Service (& Sales) are my forte, and I generally stick within those walls. Marketing traditionally was its own individual application, and only more recently has been rolled into the wider Dynamics 365 application suite. Even so, it still sometimes works in a somewhat interesting way, different from the rest of the system.

Inevitably I’ve had to actually do something with it for a client project, which has brought me to putting up this post. We had created a few marketing forms, surfaced them correctly, etc. It was great, and working well.

Then we realised that we needed to capture some additional information, in this case a list of Countries. There’s no standard entity for it within Dynamics 365, so we created our own, and loaded a list of countries (& associated data) into it. Fine – that was working without issues, including in the places that we needed to surface it.

Then we came to needing to surface the Country value on a marketing form, through a lookup. Simple, you’d have though? Well, not so much. We went to create the field, and got presented with the following error as we did so:

The error says: ‘The role marketing services user does not have access to the entities you’ve chosen…’

In essence, the system was telling us that we weren’t able to access the entity. Though Country is a custom entity, we were logged in as users with the System Administrator role (which has access automatically to ALL entities). This left us puzzling around what to do.

The error message, thankfully, was quite clear. It was referring to a specific security role missing privileges. In this case, it was the ‘Marketing Services User’. I therefore went to check the permissions for it, and sure enough, it didn’t have permissions on the Country entity that I had created!

Now usually if a security role is missing permissions, what we do is create a custom security role (usually copying the existing role), and add the permissions to do. Best practise is NOT to edit the default security roles. The (main) reason behind this is that Microsoft could update the security role in a later update/release, which could impact on us. We therefore use custom roles to avoid this happening (& yes, I’ve seen it happen/impact in practise!).

The fly in the soup here (lovely phrase, I know) is that we couldn’t do that here. It seems that Dynamics 365 for Marketing uses an underlying security role that’s needed. Even if we had implemented a custom role, we didn’t have any idea of how to tell the system to actually use our custom role, rather than the default one that it’s currently using. Quite frustrating, I tell you!

So in the end we decided to give the default security role the necessary permissions, and see what happened:

With having granted the security permissions to the role, & saved it, we then attempted to create the marketing form field field. This time, we were successful! No errors occurred during it, thankfully:

So in summary, I still have no idea why this has happened. I’ve taken a look around, but can’t find anything obvious as to how/why it actually works like this. I guess that I’d need to dig ‘under the hood’ somewhat to see what’s actually going on, and how to dealt with it appropriately. For the moment, the solution is in place, and is working.

We’ve also been very careful (as mentioned above) to add just the specific custom entity to the default security role. We haven’t touched anything else within it – all other security permissions are done (as per best practise) with custom security roles, which are then allocated appropriately to users &/or teams. Hopefully this will be fine in the long-term, though we’ll definitely be keeping our eyes on it to make sure!

Have you ever come across something like this? How did you decide to go about solving it? Drop a comment below – I’d love to hear!

Update: Thanks to the amazing Carl Cookson, it turns out that this is due to an update from Microsoft in how Marketing works. See https://docs.microsoft.com/en-gb/dynamics365/marketing/marketing-fields for more information around it. Essentially it uses this role to sync to the Azure staged Marketing service, so this role needs to have the appropriate permission

AAD Security Teams, & saving personal views

Previously I’ve touched on how it’s possible to use Azure Active Directory for Dynamics 365 security. This can be of great benefit to an organisation, especially when needing to invite in external users. The details that I go into around it can be found at Dynamics 365 Security & AAD. As I point out there, it’s a very helpful feature, and can also help with onboarding new users within an organisation.

What I’ve found out about it, however, is that there can be some very interesting little quirks with how security actually works. Originally I thought it was a bug, and raised it with Microsoft Support, but it turns out not to be. Let me take you through the journey that I experienced last week…

The scenario is as follows. We had security set up in place, which was working perfectly (or so we thought). We’d gone through all of the following steps:

  1. Create Dynamics 365 security role/s with appropriate permissions
  2. Create AAD security group
  3. Create Dynamics 365 AAD Security Team, and link it to the AAD security group
  4. Assign users to the AAD security group

This was working exceptionally well (except, of course, when the external users hadn’t followed the setup instructions correctly). Users were logging in, searching for information, creating/updating records, etc. All was good…or so we thought.

Now, the users who are actually using the application don’t have a Dynamics 365 background. It’s the first time that they’re using the specific system, and as such, are going through a learning curve. We’re not expecting them to understand the advanced functionality at this point, though some of them are indeed venturing further/deeper into the capabilities that it brings.

The Learning Curve | Listen via Stitcher for Podcasts

One of these, of course, is the Advanced Find. Now, those experienced with Dynamics 365 will know all about it. There are good points, and there are not so good points. Functionality in it has expanded over time, though to be honest it’s still easier to run a SQL query/extract for more advanced information retrieval.

Users seemed to be fine with the Advanced Find. We showed them how it works, how to filter, set up columns, etc. We even showed them how to export data to Excel, and keep a live data connection back to refresh it! Brilliant – they were most pleased.

Then I got an email in from a user needing support. They reported that they weren’t able to save custom searches. This is of course very helpful, in order to avoid having to set up the same search/layout every time. This seemed puzzling to me, and I started to take a look into it.

Always download the error log file – it can be SO useful!

I was able to replicate the problem immediately with a test user, having assigned it the same security role. Opening the log file (which can be extremely helpful at times with troubleshooting), I looked to see what the issues were. I was thinking it was a problem with security permissions – if I assigned the system administrator role to my user, everything worked just fine.

Incidentally, there’s a really good blog post at https://www.powerobjects.com/blog/2015/02/13/access-denied-identify-fix-security-role-issue/ which covers troubleshooting security role issues. I’ve used it on several occasions previously.

In my error log, there were repeated references to ‘ObjectTypeCode”:4230’. This is the View settings in the security role. I therefore went to the security role, and ensured that it was set to allow access to Saved View across all permissions:

It’s only possible to set User-level permissions for Saved Views

Right – permissions set, all should be good. Let’s go ahead & try to save an Advanced Find as a view…but no! It’s still not working, and showing the same error message!

What I then tried to do was apply the security role directly to the user, rather than through the AAD security team. To my surprise (well, not really, actually), it worked. I was able to save Advanced Find views. I changed back to the user getting permissions through the security group (ie not directly), and again I had the issue.

OK – so I thought I had discovered a bug. As far as I was aware, I couldn’t see any reason why the user wouldn’t be able to save the Advanced Find view. After all, they’re able to create & save records within the system. There surely shouldn’t be any difference between saving records, and saving an Advanced Find view?

Stressful woman looks with puzzled expression into screen, wears formal shirt, busy with making financial report, feels worried about deadlines, feels headache from recieving bad news Premium Photo

My next step was to raise a support ticket with Microsoft, and then carry out the obligatory ‘show & tell’ to the support agent. Ivan (the agent assigned to my case) was very helpful, understood exactly what I was trying to accomplish, and what the issue seemed to be. I left him with the support case, and focused on trying to find a workaround for the situation.

After a few days, Ivan came back to me with a resolution. It wasn’t a bug in the system (which was a shame – I was looking forward to having it attributed to me!), but rather a specific case of permissions.

See, there’s something called ‘privilege inheritance’. In a nutshell, there are two ways of giving access through a security role:

  1. User privileges. This is when the user is given the permissions directly
  2. Team privileges. This is when the user is given the permissions as a member of the team. If they don’t have User privileges of their own, they can only create records with the team as the owner

There’s a good article on this at https://docs.microsoft.com/en-gb/power-platform/admin/security-roles-privileges#team-members-privilege-inheritance

So what was actually happening was as follows:

  • Users were able to read, create, update records without issues, as the team was the owner of these records
  • However as views need to be owned by a user (though they can be shared with a team), the user was unable to save them!

Thankfully it’s quite easy to fix – on the security role itself, you change it here:

With this then in place, everything then worked just fine. The user was still getting the role through the Security Team, but was now able to save these directly.

Quite an interesting little quirk, but one that is likely to come in useful when looking at other functionality within the system.

Have you come across this before? Have you found anything else that seems a little strange? Comment below – I’d love to hear!
